The Automatic C Shaped Purlin Cee Purlin Roll Forming Machine. Its core working principle is to feed the strip steel from the tail of the equipment, continuously cold bend it through a series of precision pressure rollers, and finally output standard C-shaped steel from the head.
A complete fully automatic C-shaped steel production line usually consists of the following parts:
• Passive loading rack (discharge rack)
• Leveling device
• Forming host (rolling mill)
• Punching device
• Cutting device after molding (such as automatic flying saw)
• hydraulic power unit
• Computer control system (PLC control)
Main features of the machine：
1.Highly automated, high production efficiency
The equipment integrates processes such as automatic feeding, leveling, forming, fixed length cutting, and automatic punching. Adopting PLC computer control system, it is easy to operate and can achieve continuous production, greatly simplifying the tedious process of manual handling and multiple processing in traditional technology.
2.Excellent product performance and diverse specifications
The rolled C-shaped steel products have good flatness and excellent bending resistance, compression resistance, and tensile bending performance. Modern equipment usually has strong adjustability and can quickly switch between producing C-shaped steel of different heights (commonly 80mm-300mm) and thicknesses (commonly 1.5mm-3.0mm). Some models can even achieve rapid switching between C-shaped and Z-shaped steel.
3.Sturdy structure and stable operation
The rolling mill of the equipment is usually made of high hardness bearing steel (such as GR15) forged and annealed, which has strong wear resistance; The base is mostly made of heavy-duty I-beams to ensure low vibration and high stability of the equipment during high-speed operation.
Core application scenarios：
• Steel structure buildings (factories, warehouses, etc.)
This is the most traditional application field of C-shaped steel. It is mainly used as roof purlins and wall purlins, installed between the main steel beams, to support roof panels and wall panels such as color steel tiles. Widely used in large and medium-sized industrial plants, warehouses, locomotive depots, exhibition halls, sports venues and other buildings.
• Photovoltaic bracket system
With the development of new energy, C-shaped steel is widely used in photovoltaic power plants. It is used as the beam, column, slant support and other supporting structures of photovoltaic modules. Due to the fact that C-shaped steel is usually hot-dip galvanized, it has strong corrosion resistance and a perforated design that facilitates quick assembly without welding on site.
• Seismic resistant light steel structure system
Galvanized C-shaped steel is used to form the load-bearing frame (columns and beams) of light steel structures such as low rise houses and prefabricated houses. By connecting with bolts or self drilling screws, the entire system has good ductility and seismic energy dissipation capacity.
Pattern diagram:
Product Attributes :
|
1.Formed Material
|
PPGI,GI,AI
|
Thickness:14/12 gauge
|
||
|
2.Decoiler
|
Hydraulic automatic decoiler
|
5 ton
|
||
|
3.Main body
|
Roller station
|
12 rows(As your requirement)
|
||
|
Diameter of shaft
|
75 mm solid shaft
|
|||
|
Material of rollers
|
Gcr 12 with quenched teeatment
|
|||
|
Machine body frame
|
use screw fix on the frame
|
|||
|
Drive
|
Chains transmission
|
|||
|
Dimension(L*W*H)
|
6500*800*1200(customize)
|
|||
|
Weight
|
About 5T
|
|||
|
4.Cutter
|
Automatic
|
cr12mov material, no scratches, no deformation
|
||
|
5.Power
|
Motor Power
|
15KW
|
||
|
Hydraulic system power
|
5.5KW
|
|||
|
6.Voltage
|
380V 50Hz 3Phase
|
As your requirement
|
||
|
7.Control system
|
Electric Box
|
Customized(famous brand)
|
||
|
Language
|
English(Support multiple languages)
|
|||
|
PLC
|
Automatic production of the whole machine. Can set batch, length, quantity, etc.
|
|||
|
18.Forming Speed
|
25/min(customized)
|
The speed depends on the shape of the tile and the thickness of the material.
|
||
