High-Performance CT Shaft Stud and Track Roll Forming Machine It is a high-precision cold bending forming equipment designed specifically for the manufacturing of modern building steel structure frames. This equipment uses continuous cold bending forming technology to gradually process galvanized steel coils into standardized CT Shaft Stud and matching Track profiles.

CT axis stud is a metal stud specifically designed for shaft wall systems, widely used in vertical enclosure structures of buildings to accommodate water supply and drainage pipelines, electrical circuits, and ventilation systems. This equipment adopts a multi pass precision forming rolling mill, combined with a streamlined operation process of automatic unwinding, precise feeding, leveling, punching, continuous forming, fixed length hydraulic cutting, and automatic discharge, effectively eliminating material wrinkling, profile deformation, and dimensional errors in the production process. The entire production line is fully automated and equipped with an advanced PLC control system. The forming tolerance can be controlled within ± 0.1mm, ensuring the consistency and flatness of the profile section and perfect adaptation for subsequent installation.

Application Scenarios：

1. Elevator shaft and shaft enclosure system

CT axis screws are designed specifically for vertical shaft wall systems and are the core frame components of vertical enclosure structures such as elevator shafts, stairwells, equipment pipe shafts, and ventilation shafts in modern high-rise buildings. Compared with traditional masonry shafts, the light steel shaft frame system significantly reduces the overall weight of the building structure. Installation personnel can complete construction from one side of the wall without the need to build complex scaffolding inside the elevator shaft. The system has both excellent fire resistance and sound insulation performance.

2. Dry wall partitions and indoor partition systems

The C-shaped bolts and U-shaped tracks produced by the equipment are the core skeleton materials of drywall partition systems, widely used in indoor non load bearing partitions of office buildings, hotels, hospitals, shopping malls, residential apartments and other buildings. Compared to traditional wooden or block partition walls, light steel keel partition wall systems are faster to install, lighter in weight, and have better fire resistance.

3. Ceiling frame and ceiling system

The produced light steel keel profiles can be used for ceiling frame systems in various buildings, including large-scale ceilings in commercial complexes, suspended ceilings in industrial plants, equipment bearing ceilings, and other scenarios.

Pattern diagram：

Machine advantages:

1. High‑precision forming with CT solid main shaft design

2. High‑speed fully automatic production

3. Integrated inline punching function

4. Robust heavy‑duty machine frame for continuous running

5. Strong production flexibility & quick specification change

Product Attributes :

Core Features：

1. Ultra high molding accuracy, stable and reliable quality

The equipment adopts CNC precision machined alloy steel rollers (hardness HRC 58-62), combined with a high rigidity integral welded frame structure, to ensure precise and consistent forming dimensions for each pass. The forming tolerance can reach ± 0.1mm, with smooth edges, uniform cross-section, and excellent straightness of the profile, providing reliable assembly compatibility for subsequent installation of vertical shaft walls.

2. Fully automatic PLC intelligent control, efficient and labor-saving

Equipped with advanced PLC control system and touch screen operation interface, operators can easily set production parameters (length, quantity, speed), and the system monitors production status in real time. The entire process from unwinding, feeding, leveling, forming to cutting to length is automated and continuously operated, requiring only 1-2 operators to complete the control of the entire production line. The servo tracking punching system can achieve a hole spacing positioning accuracy of ± 0.01- ± 0.1mm.

3. Flexible width adjustment, one machine with multiple functions

The equipment has an adjustable width design, which allows for quick switching between different specifications of CT bolts and track profiles for production without the need to replace the entire set of rollers. This flexible feature significantly reduces mold investment costs, helps manufacturers quickly respond to diverse needs of different projects, and improves production flexibility.

4. Durable and sturdy industrial grade construction

The spindle is made of 45 # forged steel that has undergone heat treatment and precision machining; The rolling mill is made of GCr15 bearing steel or high-grade Cr12 steel, with a surface treated with hard chromium. The whole machine has strong structural rigidity and stable operation, which can meet the continuous industrial production needs around the clock. It has a long service life and low maintenance costs.

5. Integrated hydraulic cutting and precision punching

Integrated hydraulic cutting unit to achieve smooth cutting without burrs or deformations. The online punching system can complete hole processing before forming, with one-time forming and synchronous punching, greatly improving production efficiency.

Contact Us：

The High Performance CT Shaft Stud and Track Roll Forming Machine, with its comprehensive advantages of high precision, high efficiency, and high flexibility, has become an indispensable core equipment in the field of modern light steel structure construction, helping the global construction industry continue to move towards green, efficient, and standardized directions.
