Recommend machine:

A high – efficiency metal floor deck roll forming machine, which is a specialized equipment in the construction and manufacturing industry, is designed to transform flat metal sheets into floor deck profiles precisely and speedily by bending and shaping the metal through a series of rollers. It usually consists of an unwind stand for the raw metal coil, forming rollers for shaping, a cutting mechanism for getting the right lengths, and a control system that adjusts the roller speed and cutting process to ensure accurate and efficient production. This machine not only enables the mass production of floor decks used to support concrete slabs and distribute loads in building construction with high – speed production rates, reducing manufacturing time and costs and increasing productivity, but also ensures the consistency and quality of the formed floor decks because of the highly repeatable mechanical process.

Floor deck roll forming machine:

floor deck

This is the floor deck drawing for your reference:

High - efficiency metal floor deck roll forming machine

Basic information of floor deck roll forming machine:

  1. Decoiler:5tons

High - efficiency metal floor deck roll forming machine

2.roll forming machine:

Feeding&Guiding device Placed on the machine by selle
Rolling shaft materia 45# STEEL
Shaft diameter 85 mm
Roller material 45# steel
Rolling station 28stations
Work speed 10-15 m/min
Machine structure Middle plate welded frame
Machine basic frame 400# H steel welded
Bearing Roller bearing
Work power 15 kw  X 2台
Transmission By Chains



High - efficiency metal floor deck roll forming machine

High - efficiency metal floor deck roll forming machine

Control system

High - efficiency metal floor deck roll forming machine

Hydraulic system

High - efficiency metal floor deck roll forming machine

We have many years of manufacturing experience in cold – roll forming equipment. Feel free to consult us if needed.
