The R101 Trapezoidal Roof Tile Roll Forming Machine Ibr Roof Sheet Making Machine is a core piece of automated equipment for metal roof cold bending. Through a multi-roller cold bending process, it forms standard trapezoidal roof panels from color-coated steel, galvanized steel, and aluminum-magnesium-manganese coils in one pass. It is widely used in steel structure factory buildings, warehouses, venues, and greenhouse roofing projects. The equipment uses metal coils as raw material, featuring a fully closed process including hydraulic uncoiling → multi-roller progressive cold bending → servo length-tracking cutting → automatic discharge stacking. Operating at room temperature without heating, it continuously rolls and forms neat trapezoidal wave roof tiles with tightly interlocking seams and excellent waterproof sealing performance.
Pattern diagram:
Main application scenarios：
The trapezoidal metal tiles produced by this equipment have the advantages of high strength, light weight, fast installation, waterproof and fireproof, so they are widely used:
• Industrial and civil construction:
This is the most important application field. The produced roof panels and wall panels are widely used for roofs and walls in large factories, warehouses, workshops, and are also commonly found in agricultural greenhouses, breeding farms, prefabricated houses, and other buildings.
• Commercial and public facilities:
Due to their beauty and durability, they are also used on the roofs and enclosures of public buildings such as sports arenas, exhibition centers, stations, and gas stations.
• New building materials manufacturing:
In the building materials production industry, it is the core production equipment used for mass production of standard trapezoidal color steel tiles, galvanized tiles and other finished products to supply the downstream construction market.
Product Attributes :
|
1.Formed Material
|
PPGI,PPGL,AI,Etc.
|
Material Thickness:0.3-0.6mm
|
||
|
2.Decoiler
|
Hydraulic decoiler(optional)
|
will give you as free
|
||
|
3.Main body
|
Roller station
|
21rows(Due to your requirement profile)
|
||
|
Diameter of shaft
|
Due to your requirement profile
|
|||
|
Material of rollers
|
45# steel, hard chrome plated on the surface
|
|||
|
Machine body frame
|
Due to your requirement profile
|
|||
|
Drive
|
Chain transmission
|
|||
|
Dimension(L*W*H)
|
Due to design
|
|||
|
Weight
|
Due to design
|
|||
|
4.Cutter
|
Automatic
|
cr12mov material, no scratches, no deformation
|
||
|
5.Power
|
Motor Power
|
5.5KW(normally)
|
||
|
Hydraulic system power
|
5.5KW
|
|||
|
6.Voltage
|
As your requirement
|
As your requirement
|
||
|
7.Control system
|
Electric Box
|
Customized(famous brand)
|
||
|
Language
|
Support multiple languages
|
|||
|
PLC
|
Automatic production of the whole machine. Can set batch, length, quantity, etc.
|
|||
|
18.Forming Speed
|
0-80m/min
|
Provide customized
|
||
Core Advantages of the Equipment：
1.High Precision:
The trapezoidal wave crest, wave spacing, and panel length have minimal tolerances, ensuring tight roof overlaps for effective leakage and seepage prevention
2.Stable efficiency:
Variable frequency speed regulation, conventional 15–30m/min, capable of 24-hour continuous mass production with no downtime for shearing, ensuring no loss of production capacity
3.Durable and Resilient:
The heavy-duty steel structure body features wear-resistant rollers that resist deformation, ensuring low vibration and minimal failure rates during prolonged operation
4.High versatility:
Suitable for 0.3–0.8mm color steel, galvanized, and galvalume sheets, capable of producing common trapezoidal profiles such as 840/900/1050
5.Simple operation:
CNC visual debugging allows beginners to quickly get started, with convenient maintenance and upkeep
